ES-4515 LED TV Backlight use for 55" Philips D: 20231216 11605-500153 40-JFCCHD-DLA1AG U: 20231216 11605-500152 40-JFCCHU-DLA1AG LED BACKLIGHT KITS(8)
Publish Date:2024-09-14 Visits:244
Length: D=U:464MM*522MM
Voltage:3V
LED Quantity: D: 288LEDs U: 288LEDs
Original Code:D: 20231216 11605-500153 40-JFCCHD-DLA1AG U: 20231216 11605-500152 40-JFCCHU-DLA1AG
ES Model: ES-4515-D/288 BLUE ES-4515-U/288 BLUE
Brands: use for Philips
Complete Set: 1SET=4D+4U
Length: D=U:464MM*522MM
Voltage: 3V
Original Code:D: 20231216 11605-500153 40-JFCCHD-DLA1AG U: 20231216 11605-500152 40-JFCCHU-DLA1AG
Panel Sticker Number: /
TV Models: /
