ES-439 LED TV Backlight use for Arcelik 48" 48_apollon_7x7+7x6_2121C_6S1P_NH_R1/L1/R2/L2 P76 4x6_ZBG60600-AC Non Horizontal REV.V2 2014/07/11 LED STRIPS(17)
Publish Date:2020-05-21 Visits:1280
LED Quantity: R1:6LEDs L1:7LEDs R2:6LEDs L2:7LEDs
Original Code:
48_apollon_7x7+7x6_2121C_7S1P_NH_R1 P76 3x7_ZBH60600-AB Non Horizontal REV.V1
48_apollon_7x7+7x6_2121C_6S1P_NH_R1 P76 3x6_ZBH60600-AB Non Horizontal REV.V2
48_apollon_7x7+7x6_2121C_7S1P_NH_L2 P76 3x7_ZBH60600-AB Non Horizontal REV.V1
48_apollon_7x7+7x6_2121C_7S1P_NH_L1 P76 4x7_ZBE60600-AB Non Horizontal REV.V1
ES Model: ES-439-L1/7 ES-439-L2/7 ES-439-R1/6 ES-439-R2/6
Brands: use for Arcelik
Complete Set: 1SET=4R1+3R2+4L1+3L2
Length: R1:442mm+C L1:515mm+C R2:442MM+C L2:518MM+C
Original Code:
48_apollon_7x7+7x6_2121C_6S1P_NH_R1 P76 4x6_ZBH60600-AB Non Horizontal REV.V2
48_apollon_7x7+7x6_2121C_6S1P_NH_R2 P76 3x6_ZBH60600-AB Non Horizontal REV.V2
48_apollon_7x7+7x6_2121C_7S1P_NH_L1 P76 4x7_ZBH60600-AB Non Horizontal REV.V1
48_apollon_7x7+7x6_2121C_7S1P_NH_L2 P76 3x7_ZBE60600-AB Non Horizontal REV.V1
Panel Sticker Number: /
TV Models: AK48M5C49Z4018200286BG，G48L95634B，057U48-A05AK48NZC5A94018100266, A48LB9486, 48VLX8585BP G48L95634B, A48L
9562 5B BEKO B48 LB 9486 LED BAR, A48 LB 9486, G48L 9563 4B
