ES-3558 LED TV Backlight use for 48" Panasonic/Toshiba LA: 480DLED_SLIM_A-LEFT-TYPE_Rev0.3_20200728 RA: 480DLED_SLIM_A-RIGHT-TYPE_Rev0.3_20200728 LB: 480DLED_SLIM_B-LEFT-TYPE_Rev0.3_20200728 RB: 480DLED_SLIM_B-RIGHT-TYPE_Rev0.3_20200728 LED STRIP(12)
Publish Date:2022-11-23 Visits:1519
Length: LA:390MM LB:433MM RA:537MM RB:494MM
Voltage:3V
LED Quantity: LA: 5LEDs LB: 6LEDs RA: 6LEDs RB: 6LEDs
Original Code:
LA: 480DLED_SLIM_A-LEFT-TYPE_Rev0.3_20200728
RA: 480DLED_SLIM_A-RIGHT-TYPE_Rev0.3_20200728
LB: 480DLED_SLIM_B-LEFT-TYPE_Rev0.3_20200728
RB: 480DLED_SLIM_B-RIGHT-TYPE_Rev0.3_20200728
ES Model: ES-3558-LA/5 ES-3558-LB/6 ES-3558-RA/6 ES-3558-RB/6
Brands: use for Panasonic/Toshiba
Complete Set: 1SET=4LA+4RA+2LB+2RB
Length: LA:390MM LB:433MM RA:537MM RB:494MM
Voltage: 3V
Original Code:
LA: 480DLED_SLIM_A-LEFT-TYPE_Rev0.3_20200728
RA: 480DLED_SLIM_A-RIGHT-TYPE_Rev0.3_20200728
LB: 480DLED_SLIM_B-LEFT-TYPE_Rev0.3_20200728
RB: 480DLED_SLIM_B-RIGHT-TYPE_Rev0.3_20200728
Panel Sticker Number: VES480QNSS-3D-U01
TV Models:
use for Panasonic: TX-48CX400B, TX-48CX350B, TX-48CXW404,TX-48CX400E, TX-48CX400B,
use for Toshiba : 48S3653DB, 48U7653DB
